10368-30-1-0500-002-1-TS

Active

CnC Tech, LLC

HOOK-UP STRND 30AWG WHITE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsMicrosoft Word - Color cards-10368.docx Datasheet Prior to DC 22/03 +1

10368-30-1-0500-002-1-TS

Active

CnC Tech, LLC

HOOK-UP STRND 30AWG WHITE

Deep-Dive with AI

DocumentsMicrosoft Word - Color cards-10368.docx Datasheet Prior to DC 22/03 +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	10368-30-1-0500-002-1-TS

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Features	Oil Resistant
Jacket (Insulation) Diameter [diameter]	0.84 mm
Jacket (Insulation) Diameter [diameter]	0.033 in
Jacket (Insulation) Material	Polyethylene (XLPE), Irradiated
Jacket (Insulation) Thickness	0.25 mm
Jacket (Insulation) Thickness	0.01 in
Length	15.24 m
Length [x]	50 ft, 500 ', 25 ft
Length [x]	152.4 m, 7.62 m
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-10 °C
Ratings	UL Style 10368
Voltage	300 V
Wire Gauge	30 AWG

10368-30 Series

Part	Length [x]	Length [x]	Features	Jacket (Insulation) Material	Length	Cable Type	Conductor Material	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Ratings	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage
CnC Tech, LLC 10368-30-1-0500-006-1-TS	25 ft 50 ft 100 ft 500 '	7.62 m 30.5 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Brown	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-010-1-TS	50 ft 100 ft	30.5 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.79 mm	0.031 in	30 AWG	UL Style 10368	Violet	0.23 mm	0.009 in	300 V
CnC Tech, LLC 10368-30-1-0500-011-1-TS	50 ft 100 ft 500 '	30.5 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Green Yellow	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-005-1-TS	25 ft 50 ft 500 '	7.62 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Blue	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-008-1-TS	25 ft 50 ft 100 ft 500 '	7.62 m 30.5 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Orange	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-001-1-TS	25 ft 50 ft 100 ft 500 '	7.62 m 30.5 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Black	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-003-1-TS	50 ft 100 ft	30.5 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Yellow	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-007-1-TS	25 ft 50 ft 500 '	7.62 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Green	0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-002-1-TS	25 ft 50 ft 500 '	7.62 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated	15.24 m	Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368		0.25 mm	0.01 in	300 V
CnC Tech, LLC 10368-30-1-0500-004-1-TS	25 ft 100 ft 500 '	7.62 m 30.5 m 152.4 m	Oil Resistant	Polyethylene (XLPE) Irradiated		Hook-Up	Copper Tinned	105 ░C	-10 °C	0.84 mm	0.033 in	30 AWG	UL Style 10368	Red	0.25 mm	0.01 in	300 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 5.55
		1	$ 12.27
		2	$ 9.27
		2	$ 5.27
		4	$ 5.04
		5	$ 8.66
		10	$ 4.70
		10	$ 8.24
		20	$ 7.87
		20	$ 4.50
		40	$ 4.26
		50	$ 7.35
		100	$ 4.00
		100	$ 7.02
		200	$ 3.80
		200	$ 6.65
		400	$ 3.62
		500	$ 6.23
		500	$ 0.15
		1000	$ 0.14
		2500	$ 0.13
		5000	$ 0.12
		12500	$ 0.12
		25000	$ 0.11
		50000	$ 0.10

Description

General part information

10368-30 Series

30 AWG Hook-Up Wire 7/0.0039" White 300V 500.0' (152.4m)

Documents

Technical documentation and resources

Microsoft Word - Color cards-10368.docx

Datasheet Prior to DC 22/03

Datasheet
