5645-II

Active

BRADY

B689 5645-II BLK/YEL STYLE II

Search across all available documentation for this part.

Active

BRADY

B689 5645-II BLK/YEL STYLE II

Technical Specifications

Parameters and characteristics for this part

Specification	5645-II

Application Specifics	Notice
Applications	Pipe
Arrangement	Symbol and Text
Color - Background	Yellow
Color - Legend	Black
Features	Chemical Resistant
Language	English
Legend (Symbol Only)	Directional Arrow
Legend (Text)	Chemical Feed
Length	26 in
Length	660.4 mm
Location	Outdoor
Material - Body	Plastic
Mounting Type	Snap On
Outside Pipe Diameter (Max) [diameter]	2.5 "
Outside Pipe Diameter (Max) [diameter]	63.5 mm
Outside Pipe Diameter (Min) [Min] [diameter]	200.03 mm
Outside Pipe Diameter (Min) [Min] [diameter]	7.875 in
Print Type	Pre-Printed
Shape	Rectangle
Width	304.8 mm
Width [x]	12 in

Part	Applications	Language	Width [x]	Width [x]	Legend (Text)	Outside Pipe Diameter (Max) [diameter]	Outside Pipe Diameter (Max) [diameter]	Print Type	Color - Background	Features	Location	Application Specifics	Material - Body	Mounting Type	Legend (Symbol Only)	Arrangement	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Length	Length	Color - Legend	Shape	Outside Pipe Diameter (Min) [Min] [diameter]	Width [y]	Width [y]	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Width
BRADY 5645-I	Pipe	English	8 in	203.2 mm	Chemical Feed	1.5 "	38.1 mm	Pre-Printed	Yellow	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Outdoor	Directionality	Plastic	Snap On	Directional Arrow	Symbol and Text	2.375 in	60.33 mm	9 "	228.6 mm	Black	Rectangle
BRADY 5645-O	Pipe	English			Chemical Feed			Pre-Printed	Yellow	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Outdoor	Directionality	Plastic	Snap On	Directional Arrow	Symbol and Text	1.375 in		8 in	203.2 mm	Black	Rectangle	34.93 mm	127 mm	5 in	12.7 mm	0.5 "
BRADY 5645-II	Pipe	English	12 in		Chemical Feed	2.5 "	63.5 mm	Pre-Printed	Yellow	Chemical Resistant	Outdoor	Notice	Plastic	Snap On	Directional Arrow	Symbol and Text	7.875 in	200.03 mm	26 in	660.4 mm	Black	Rectangle						304.8 mm
