SRP7030-3R3M
ActiveBourns Inc.
IND7X7.8X3.2MM,3.3UH20%6A,SHDSMD /TAPE & REEL - 13" REEL ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
SRP7030-3R3M
ActiveBourns Inc.
IND7X7.8X3.2MM,3.3UH20%6A,SHDSMD /TAPE & REEL - 13" REEL ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP7030-3R3M |
|---|---|
| Current - Saturation (Isat) | 10 A |
| Current Rating (Amps) | 6 A |
| DC Resistance (DCR) [Max] | 30 mOhm |
| Height - Seated (Max) [Max] [z] | 3.2 mm |
| Height - Seated (Max) [Max] [z] | 0.126 in |
| Inductance | 3.3 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Iron |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.307 in |
| Size / Dimension [x] | 7.8 mm |
| Size / Dimension [y] | 0.276 in |
| Size / Dimension [y] | 7 mm |
| Tolerance | 20 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.26 | |
| 10 | $ 1.06 | |||
| 25 | $ 0.97 | |||
| 50 | $ 0.91 | |||
| 100 | $ 0.75 | |||
| 250 | $ 0.70 | |||
| 500 | $ 0.66 | |||
| Digi-Reel® | 1 | $ 1.26 | ||
| 10 | $ 1.06 | |||
| 25 | $ 0.97 | |||
| 50 | $ 0.91 | |||
| 100 | $ 0.75 | |||
| 250 | $ 0.70 | |||
| 500 | $ 0.66 | |||
| Tape & Reel (TR) | 1000 | $ 0.60 | ||
| 3000 | $ 0.58 | |||
| 5000 | $ 0.56 | |||
| 10000 | $ 0.54 | |||
| Newark | Each (Supplied on Full Reel) | 1000 | $ 0.66 | |
| 2000 | $ 0.60 | |||
| 4000 | $ 0.54 | |||
| 6000 | $ 0.52 | |||
| 10000 | $ 0.51 | |||
Description
General part information
SRP7030 Series
3.3 µH Shielded Inductor 6 A 30mOhm Max Nonstandard
