IXD5120N152NR-G

Active

Zilog

IC SUPERVISOR 1 CHANNEL SSOT24

Search across all available documentation for this part.

Active

Zilog

IC SUPERVISOR 1 CHANNEL SSOT24

Technical Specifications

Parameters and characteristics for this part

Specification	IXD5120N152NR-G

Mounting Type	Surface Mount
Number of Voltages Monitored	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output	Open Drain or Open Collector
Package / Case	SC-82
Reset	Active Low
Supplier Device Package	SSOT-24
Type	Simple Reset/Power-On Reset
Voltage - Threshold	1.5 V

Part	Mounting Type	Package / Case	Type	Reset	Operating Temperature [Max]	Operating Temperature [Min]	Number of Voltages Monitored	Output	Supplier Device Package	Voltage - Threshold
Zilog IXD5120N182NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Open Drain or Open Collector	SSOT-24	1.8 V
Zilog IXD5120C182NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Push-Pull Totem Pole	SSOT-24	1.8 V
Zilog IXD5120C152NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Push-Pull Totem Pole	SSOT-24	1.5 V
Zilog IXD5120C252NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Push-Pull Totem Pole	SSOT-24	2.5 V
Zilog IXD5120C302NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Push-Pull Totem Pole	SSOT-24	3 V
Zilog IXD5120N152NR-G	Surface Mount	SC-82	Simple Reset/Power-On Reset	Active Low	85 °C	-40 °C	1	Open Drain or Open Collector	SSOT-24	1.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.58
	Digi-Reel®	1	$ 0.58
	Tape & Reel (TR)	42000	$ 0.17

General part information

Supervisor Open Drain or Open Collector 1 Channel SSOT-24
