SKA10420
ActiveCelduc Inc.
SSR 5A/230VAC/CTRL 2.5-10V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SKA10420
ActiveCelduc Inc.
SSR 5A/230VAC/CTRL 2.5-10V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SKA10420 |
|---|---|
| Approval Agency | CE, cURus, VDE |
| Load Current | 5 A |
| Mounting Type | Through Hole |
| On-State Resistance (Max) [Max] | 40 mOhms |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | AC, Zero Cross |
| Package / Case | 4-SIP |
| Supplier Device Package | 4-SIP |
| Termination Style | PC Pin |
| Voltage - Input [Max] | 10 V |
| Voltage - Input [Min] | 2.5 V |
| Voltage - Load [Max] | 275 V |
| Voltage - Load [Min] | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 20 | $ 29.68 | |
Description
General part information
SKA104 Series
Solid State SPST-NO (1 Form A) 4-SIP
Documents
Technical documentation and resources
