Technical Specifications
Parameters and characteristics for this part
| Specification | ZPA00A150L11T |
|---|---|
| Actuator Type | Lever, Straight |
| Circuit | SPST-NO |
| Current Rating (Amps) | 100 mA |
| Differential Travel | 0.8 mm |
| Differential Travel | 0.031 " |
| Electrical Life | 300000 Cycles |
| Mechanical Life | 1000000 Cycles |
| Mounting Type | Surface Mount |
| Operating Force | 39 gf |
| Operating Position | 0.343 in |
| Operating Position | 8.7 mm |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Overtravel | 0.6 mm |
| Overtravel | 0.025 " |
| Pretravel | 4.4 mm |
| Pretravel | 0.172 " |
| Release Force | 6 gf |
| Switch Function | Off-Mom |
| Termination Style | Gull Wing |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 30 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.27 | |
| 10 | $ 1.88 | |||
| 25 | $ 1.75 | |||
| 50 | $ 1.65 | |||
| 100 | $ 1.56 | |||
| Digi-Reel® | 1 | $ 2.27 | ||
| 10 | $ 1.88 | |||
| 25 | $ 1.75 | |||
| 50 | $ 1.65 | |||
| 100 | $ 1.56 | |||
| Tape & Reel (TR) | 400 | $ 1.39 | ||
| 800 | $ 1.31 | |||
| 1200 | $ 1.22 | |||
| 2800 | $ 1.18 | |||
Description
General part information
Zpa0 Series Series
C&K’s ZPA series is the newest SMT type mini size package size snap switch. It is a surface mount switch suitable for automatic pick and placed on PCB during production. Fully process sealed.
