VSK-S25-15U

Obsolete

CUI Inc.

AC/DC CONVERTER 15V 25W

Deep-Dive with AI

Search across all available documentation for this part.

VSK-S25-15U

Obsolete

CUI Inc.

AC/DC CONVERTER 15V 25W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	VSK-S25-15U

Applications	ITE (Commercial)
Approval Agency	EN, CB Scheme, UL, IEC
Current - Output (Max) [Max]	1.6 A
Efficiency	83 %
Features	Universal Input
Line Regulation	0.5 %
Load Regulation	1 %
Mounting Type	Through Hole
Number of Outputs	1
Package / Case	6-DIP Module
Power (Watts)	25 W
Standard Number	55032, 61000.32, 55024, 60950.1, 61000.33
Type	Enclosed
Voltage - Output 1	15 V
Weight	0.265 lb
Weight	120.2 g

VSK-S25 Series

Part	Efficiency	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Applications	Type	Power (Watts)	Number of Outputs	Features	Approval Agency	Voltage - Isolation	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Current - Output 1	Package / Case	Load Regulation	Weight	Weight	Standard Number	Current - Output (Max) [Max]	Line Regulation
CUI Inc. VSK-S25-15U-T	83 %	15 V	-40 °C	70 °C	Chassis Mount	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CE cURus	3000 V	96.1 mm	2.17 in	1.26 in	32 mm	3.78 in	54 mm	1.6 A
CUI Inc. VSK-S25-9U-T	78 %	9 V	-40 °C	70 °C	Chassis Mount	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CE cURus	3000 V	96.1 mm	2.17 in	1.26 in	32 mm	3.78 in	54 mm	2.5 A
CUI Inc. VSK-S25-48U	87 %	48 V			Through Hole	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CB Scheme EN IEC UL									6-DIP Module	1 %	0.265 lb	120.2 g	55024 55032 60950.1 61000.32 61000.33	500 mA	0.5 %
CUI Inc. VSK-S25-12U-T		12 V	-40 °C	70 °C	Chassis Mount	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CE cURus	3000 V	96.1 mm	2.17 in	1.26 in	32 mm	3.78 in	54 mm	2.1 A
CUI Inc. VSK-S25-15U	83 %	15 V			Through Hole	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CB Scheme EN IEC UL									6-DIP Module	1 %	0.265 lb	120.2 g	55024 55032 60950.1 61000.32 61000.33	1.6 A	0.5 %
CUI Inc. VSK-S25-48U-T	87 %	48 V	-40 °C	70 °C	Chassis Mount	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CE cURus	3000 V	96.1 mm	2.17 in	1.26 in	32 mm	3.78 in	54 mm	500 mA
CUI Inc. VSK-S25-24U	85 %	24 V			Through Hole	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CB Scheme EN IEC UL									6-DIP Module	1 %	0.265 lb	120.2 g	55024 55032 60950.1 61000.32 61000.33		0.5 %
CUI Inc. VSK-S25-24U-T	85 %	24 V	-40 °C	70 °C	Chassis Mount	ITE (Commercial)	Enclosed	25 W	1	Universal Input	CE cURus	3000 V	96.1 mm	2.17 in	1.26 in	32 mm	3.78 in	54 mm	1.1 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

VSK-S25 Series

Enclosed AC DC Converters 1 Output 15V 1.6A 85 ~ 264 VAC Input
