CI2503P1H00-LF

Obsolete

Cvilux USA

3 POS 2.50MM (.098) WIRE TO BOAR

Search across all available documentation for this part.

Obsolete

Cvilux USA

3 POS 2.50MM (.098) WIRE TO BOAR

Technical Specifications

Parameters and characteristics for this part

Specification	CI2503P1H00-LF

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	120 µin
Contact Finish Thickness - Mating	3.05 Ám
Contact Finish Thickness - Post	120 Áin
Contact Finish Thickness - Post	3.05 Ám
Contact Length - Post [x]	0.134 in
Contact Length - Post [x]	3.4 mm
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Detent Lock
Insulation Color	Ivory
Insulation Height	4.9 mm
Insulation Height	0.193 in
Insulation Material	Polyamide (PA46), Nylon 4/6
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Pitch - Mating	2.5 mm
Pitch - Mating	0.098 in
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	250 VAC

Part	Contact Finish - Post	Connector Type	Pitch - Mating	Pitch - Mating	Insulation Height	Insulation Height	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Fastening Type	Contact Length - Post [x]	Contact Length - Post [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Material Flammability Rating	Shrouding	Voltage Rating	Current Rating (Amps)	Insulation Material	Number of Rows	Style	Mounting Type	Contact Material	Number of Positions Loaded	Contact Type	Insulation Color	Overall Contact Length	Overall Contact Length
Cvilux USA CI2503P1H00-LF	Tin	Header	2.5 mm	0.098 in	4.9 mm	0.193 in	Circular	-25 °C	85 °C	Solder	Detent Lock	0.134 in	3.4 mm	120 µin	3.05 Ám	120 Áin	3.05 Ám	UL94 V-0	Shrouded - 4 Wall	250 VAC	3 A	Polyamide (PA46) Nylon 4/6	1	Board to Cable/Wire	Through Hole Right Angle	Brass	All	Male Pin	Ivory
Cvilux USA CI2503P1V00-LF	Tin	Header	2.5 mm	0.098 in	5.9 mm	0.232 in	Circular	-25 °C	85 °C	Solder	Detent Lock	0.134 in	3.4 mm	120 µin	3.05 Ám	120 Áin	3.05 Ám	UL94 V-0	Shrouded - 4 Wall	50 VAC	3 A	Polyamide (PA46) Nylon 4/6	1	Board to Cable/Wire	Through Hole	Brass	All	Male Pin	Natural	0.35 in	8.89 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Connector Header Through Hole, Right Angle 3 position 0.098" (2.50mm)
