19350 008250

Active

Belden Inc.

CABLE 3COND 18AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3COND 18AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	19350 008250

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand	34 AWG, 42
Jacket (Insulation) Diameter [diameter]	0.253 in
Jacket (Insulation) Diameter [diameter]	6.43 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.038 in
Jacket (Insulation) Thickness	0.965 mm
Jacket Color	Gray
Length	3000 "
Length	76.2 m
Number of Conductors	3
Operating Temperature	60 °C
Wire Gauge	18 AWG

Part	Conductor Insulation	Wire Gauge	Cable Type	Operating Temperature	Length	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand	Conductor Material	Number of Conductors	Jacket Color
Belden Inc. 19350 008250	Poly-Vinyl Chloride (PVC)	18 AWG	Multi-Conductor	60 °C	3000 "	76.2 m	0.038 in	0.965 mm	Poly-Vinyl Chloride (PVC)	0.253 in	6.43 mm	34 AWG 42	Copper Bare	3	Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Conductor Multi-Conductor Cable Gray 18 AWG 250.0' (76.2m)
