ULP153M010DBF1A0

Active

Cornell Dubilier Knowles

CAP ALUM 15000UF 20% 10V FLATPAC

Search across all available documentation for this part.

Active

Cornell Dubilier Knowles

CAP ALUM 15000UF 20% 10V FLATPAC

Technical Specifications

Parameters and characteristics for this part

Specification	ULP153M010DBF1A0

Applications	General Purpose
ESR (Equivalent Series Resistance)	80 mOhm
Height - Seated (Max) [Max] [z]	3.2 mm
Height - Seated (Max) [Max] [z]	0.126 in
Lifetime @ Temp.	3000 Hrs
Mounting Type	User Defined
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	FlatPack
Polarization	Polar
Size / Dimension [x]	62 mm
Size / Dimension [x]	2.441 in
Size / Dimension [y]	42 mm
Size / Dimension [y]	1.654 "
Tolerance	20 %
Voltage - Rated	10 V

Part	Lifetime @ Temp.	Applications	ESR (Equivalent Series Resistance)	Polarization	Package / Case	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance	Mounting Type
Cornell Dubilier Knowles ULP153M010DBF1A0	3000 Hrs	General Purpose	80 mOhm	Polar	FlatPack	10 V	3.2 mm	0.126 in	62 mm	42 mm	2.441 in	1.654 "	85 °C	-40 °C	20 %	User Defined

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

15000 µF 10 V Aluminum Electrolytic Capacitors FlatPack 80mOhm @ 120Hz 3000 Hrs @ 85°C
