UB204KW035F

Active

NKK Switches

INDICATOR PB SQ BRIGHT LED BLUE

Search across all available documentation for this part.

Active

NKK Switches

INDICATOR PB SQ BRIGHT LED BLUE

Technical Specifications

Parameters and characteristics for this part

Part	Type	Lens Color	Lens Style	Lens Transparency	Current	Voltage	Lens Size	Panel Cutout Shape	Lamp Color
NKK Switches UB204KW036G-1JB	LED	Blue	Square with Flat Top	Diffused	30 mA	3.6 V	15 mm	Square	Blue
NKK Switches UB204KW035C	LED		Square with Flat Top		30 mA	1.85 V	15 mm	Square	Red
NKK Switches UB204KW036B-3JB	LED	White	Square with Flat Top	Diffused		3.3 V	15 mm	Square	White
NKK Switches UB204KW035F-1JB	LED	Green	Square with Flat Top	Diffused	25 mA	2.1 V	15 mm	Square	Green
NKK Switches UB204KW035F	LED		Square with Flat Top		25 mA	2.1 V	15 mm	Square	Green
NKK Switches UB204KW036G	LED		Square with Flat Top		30 mA	3.6 V	15 mm	Square	Blue
NKK Switches UB204KW03CF-1JB	LED	White	Square with Flat Top	Diffused	25 mA 30 mA	2.1 V 3.5 V	15 mm	Square	Green Red
NKK Switches UB204KW035F-3JF	LED	Green	Square with Flat Top	Diffused	25 mA	2.1 V	15 mm	Square	Green
NKK Switches UB204KW035C-3JB	LED	White	Square with Flat Top	Diffused	30 mA	1.85 V	15 mm	Square	Red

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Green 2.1V 25mA
