ULS-12/8.3-D48PM-C

Murata Power Solutions Inc.

ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Product Change Notice EN

ULS-12/8.3-D48PM-C

Murata Power Solutions Inc.

ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ULS-12/8.3-D48PM-C

Applications	ITE (Commercial)
Control Features	Active High, Enable
Current - Output (Max) [Max]	8.3 A
Efficiency	92 %
Features	OVP, Remote On/Off, SCP, OTP, UVLO
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	1/16 Brick, 8-SMD Module
Power (Watts)	100 W
Size / Dimension [x]	1.3 "
Size / Dimension [x]	33 mm
Size / Dimension [y]	22.9 mm
Size / Dimension [y]	0.9 "
Size / Dimension [z]	0.4 "
Size / Dimension [z]	10.2 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	36 V
Voltage - Isolation	2250 VDC
Voltage - Output 1	12 V

ULS-12 Series

Part	Control Features	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Efficiency	Mounting Type	Applications	Features	Power (Watts)	Type	Number of Outputs	Voltage - Output 1	Package / Case	Size / Dimension [z]	Size / Dimension [y]
Murata Power Solutions Inc. ULS-12/8.3-D48NM-C	Active Low Enable	8.3 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	92 %	Surface Mount	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	100 W	Isolated Module	1	12 V	1/16 Brick 8-SMD Module
Murata Power Solutions Inc. ULS-12/8.3-D48P-C	Active High Enable	8.3 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	92 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	100 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick
Murata Power Solutions Inc. ULS-12/5-D48P-C	Active High Enable	5 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	91 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	60 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick
Murata Power Solutions Inc. ULS-12/5-D48PH-C	Active High Enable	5 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	91 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	60 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick
Murata Power Solutions Inc. ULS-12/8.3-D48PM-C	Active High Enable	8.3 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	92 %	Surface Mount	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	100 W	Isolated Module	1	12 V	1/16 Brick 8-SMD Module
Murata Power Solutions Inc. ULS-12/2.5-D48NL2-C	Active Low Enable	2.5 A	85 °C	-40 °C	2250 VDC	0.36 in			0.9 "	1.3 "	33 mm	75 V	36 V	87.7 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	30 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick	9.1 mm	22.9 mm
Murata Power Solutions Inc. ULS-12/5-D48NL2-C	Active Low Enable	5 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	91 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	60 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick
Murata Power Solutions Inc. ULS-12/5-D48N-C	Active Low Enable	5 A	85 °C	-40 °C	2250 VDC	0.4 "	10.2 mm	22.9 mm	0.9 "	1.3 "	33 mm	75 V	36 V	91 %	Through Hole	ITE (Commercial)	OTP OVP Remote On/Off SCP UVLO	60 W	Isolated Module	1	12 V	8-DIP Module 1/16 Brick

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	200	$ 37.46

Description

General part information

ULS-12 Series

ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A
