2MT2-1

Obsolete

Honeywell Sensing and Productivity Solutions

SWITCH TOGGLE DPDT 100MA 28V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsMicro-Toggle Switch, Line Guide

2MT2-1

Obsolete

Honeywell Sensing and Productivity Solutions

SWITCH TOGGLE DPDT 100MA 28V

Deep-Dive with AI

DocumentsMicro-Toggle Switch, Line Guide

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	2MT2-1

Actuator Length [x]	16.87 mm
Actuator Type	Standard Round
Bushing Thread	15/32-32
Circuit	DPDT
Current Rating (Amps)	100 mA
Electrical Life	60000 Cycles
Illumination	Non-Illuminated
Ingress Protection	IP67 - Dust Tight, Waterproof
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Panel Cutout Dimensions [diameter]	12.45 mm
Switch Function	On-Off-On
Termination Style	0.11 in
Termination Style	Quick Connect, Solder
Termination Style	2.8 mm
Voltage Rating - DC	28 V

2MT2 Series

Part	Current Rating (Amps)	Switch Function	Operating Temperature [Max]	Operating Temperature [Min]	Panel Cutout Dimensions [diameter]	Illumination	Electrical Life	Actuator Type	Ingress Protection	Voltage Rating - DC	Termination Style	Termination Style	Termination Style	Circuit	Actuator Length [x]	Bushing Thread
Honeywell Sensing and Productivity Solutions 2MT2-8	100 mA	On-Mom	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPDT	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-7	100 mA	Mom-Off-Mom	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPDT	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-4	100 mA	On-Mom	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPST-NC	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-2	100 mA	On-Off	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPST	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-1	100 mA	On-Off-On	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPDT	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-5	100 mA	On-Off-Mom	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPDT	16.87 mm	15/32-32
Honeywell Sensing and Productivity Solutions 2MT2-6	100 mA	Off-Mom	85 °C	-40 °C	12.45 mm	Non-Illuminated	60000 Cycles	Standard Round	IP67 - Dust Tight Waterproof	28 V	0.11 in	Quick Connect Solder	2.8 mm	DPST-NO	16.87 mm	15/32-32

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

2MT2 Series

Toggle Switch DPDT Panel Mount
