B72214M0271K000
ActiveEPCOS - TDK Electronics
VARISTOR 330V 10KA 2SMD NO LEAD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B72214M0271K000
ActiveEPCOS - TDK Electronics
VARISTOR 330V 10KA 2SMD NO LEAD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B72214M0271K000 |
|---|---|
| Capacitance @ Frequency | 870 pF |
| Current - Surge | 10 kA |
| Energy | 115 J |
| Features | High Surge |
| Grade | Automotive |
| Maximum DC Volts [Max] | 270 V |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 2-SMD, No Lead |
| Qualification | AEC-Q200 |
| Varistor Voltage (Max) [Max] | 363 V |
| Varistor Voltage (Min) [Min] | 297 V |
| Varistor Voltage (Typ) | 330 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 3.20 | |
| 5 | $ 2.33 | |||
| 10 | $ 2.05 | |||
| 40 | $ 1.62 | |||
| 200 | $ 1.28 | |||
| 400 | $ 1.17 | |||
| 600 | $ 1.13 | |||
Description
General part information
B72214M Series
330 V 10 kA Varistor 1 Circuit Surface Mount 2-SMD, No Lead
