PTVA123501FC-V1-R0
ActiveMACOM Technology Solutions
RF MOSFET LDMOS 50V H-37248-4
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PTVA123501FC-V1-R0
ActiveMACOM Technology Solutions
RF MOSFET LDMOS 50V H-37248-4
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PTVA123501FC-V1-R0 |
|---|---|
| Current - Test | 150 mA |
| Frequency [Max] | 1.4 GHz |
| Frequency [Min] | 1.2 GHz |
| Gain | 17 dBi |
| Mounting Type | Chassis Mount |
| Package / Case | H-37248-4 |
| Power - Output | 350 W |
| Supplier Device Package | H-37248-4 |
| Voltage - Rated | 105 V |
| Voltage - Test | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 364.29 | |
| 10 | $ 341.53 | |||
| 25 | $ 324.45 | |||
| Digi-Reel® | 1 | $ 364.29 | ||
| 10 | $ 341.53 | |||
| 25 | $ 324.45 | |||
| Tape & Reel (TR) | 50 | $ 324.45 | ||
Description
General part information
PTVA123501 Series
RF Mosfet 50 V 150 mA 1.2GHz ~ 1.4GHz 17dB 350W H-37248-4
