PKM17EWH2001

Obsolete

Murata Power Solutions Inc.

BUZZER PIEZO 3V 16.8MM FLANGE

Search across all available documentation for this part.

Obsolete

Murata Power Solutions Inc.

BUZZER PIEZO 3V 16.8MM FLANGE

Technical Specifications

Parameters and characteristics for this part

Specification	PKM17EWH2001

Driver Circuitry	Externally Driven, Transducer
Frequency	2 kHz
Height - Seated (Max) [Max] [z]	0.295 in
Height - Seated (Max) [Max] [z]	7.5 mm
Input Type	Peak-Peak Signal
Mounting Type	Panel Mount, Flange
Operating Mode	Ringer
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Port Location	Top
Size / Dimension [diameter]	0.661 in
Size / Dimension [diameter]	16.8 mm
Sound Pressure Level (SPL)	70 dB
Technology	Piezo
Termination	Wire Leads
Voltage - Rated	3 VDC

Part	Operating Mode	Frequency	Sound Pressure Level (SPL)	Input Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Termination	Port Location	Technology	Mounting Type	Driver Circuitry	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Murata Power Solutions Inc. PKM17EWH2001	Ringer	2 kHz	70 dB	Peak-Peak Signal	0.661 in	16.8 mm	Wire Leads	Top	Piezo	Flange Panel Mount	Externally Driven Transducer	-20 C	70 °C	3 VDC	0.295 in	7.5 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Buzzers Transducer, Externally Driven Piezo 3 V 2kHz 70dB @ 3V, 10cm Panel Mount, Flange Wire Leads
