2-1904058-5
ActiveTE Connectivity Potter & Brumfield Relays
RELAY AUTO SPST-NO 20A 12V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2-1904058-5 |
|---|---|
| Coil Current | 240 mA |
| Coil Power | 2.9 W |
| Coil Resistance | 50 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 12 VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Material | Silver (Ag) |
| Contact Rating (Current) | 20 A |
| Mounting Type | Through Hole |
| Must Operate Voltage | 6.9 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 2.5 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Release Time | 1 ms |
| Switching Voltage | 400 VDC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 63.56 | |
| 10 | $ 55.52 | |||
| 25 | $ 52.61 | |||
| 50 | $ 50.51 | |||
| 100 | $ 48.50 | |||
Description
General part information
1904058 Series
RELAY AUTO SPST-NO 20A 12V
Documents
Technical documentation and resources
No documents available
