MOVHE20V190Y-AP
ActiveEaton - Electronics Division
VARISTOR 190 VAC HE 20MM DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOVHE20V190Y-AP
ActiveEaton - Electronics Division
VARISTOR 190 VAC HE 20MM DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOVHE20V190Y-AP |
|---|---|
| Capacitance @ Frequency | 1300 pF |
| Current - Surge | 10 kA |
| Energy | 210 J |
| Maximum AC Volts [Max] | 190 V |
| Maximum DC Volts [Max] | 250 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc 20mm |
| Varistor Voltage (Max) [Max] | 330 V |
| Varistor Voltage (Min) [Min] | 270 V |
| Varistor Voltage (Typ) | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 500 | $ 0.52 | |
Description
General part information
MOVHE20 Series
300 V 10 kA Varistor 1 Circuit Through Hole Disc 20mm
