ACBP-N-50A
ActiveOptiFuse
CIR BRKR 50A 32VDC AUTO RESET
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ACBP-N-50A
ActiveOptiFuse
CIR BRKR 50A 32VDC AUTO RESET
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ACBP-N-50A |
|---|---|
| Actuator Type | Automatic Reset |
| Approval Agency | IP 63, SAE J1171, SAE J553 |
| Breaker Type | Shortstop |
| Current Rating (Amps) | 50 A |
| Illumination | None |
| Number of Poles | 1 |
| Voltage Rating - DC | 32 V |
ACBP-N Series
| Part | Breaker Type | Approval Agency | Current Rating (Amps) | Number of Poles | Actuator Type | Voltage Rating - DC | Illumination |
|---|---|---|---|---|---|---|---|
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 15 A | 1 | Automatic Reset | 32 V | None |
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 15 A | 1 | Automatic Reset | 32 V | None |
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 50 A | 1 | Automatic Reset | 32 V | None |
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 10 A | 1 | Automatic Reset | 32 V | None |
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 30 A | 1 | Automatic Reset | 32 V | None |
OptiFuse | Shortstop | IP 63 SAE J1171 SAE J553 | 40 A | 1 | Automatic Reset | 32 V | None |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.88 | |
| 10 | $ 3.65 | |||
| 25 | $ 3.41 | |||
| 50 | $ 3.18 | |||
| 100 | $ 2.90 | |||
| 250 | $ 2.85 | |||
| 500 | $ 2.76 | |||
| 1000 | $ 2.67 | |||
Description
General part information
ACBP-N Series
Circuit Breaker Shortstop 50A AC 32 V DC Automatic Reset
