082SM.01000.00

Active

Astrodyne TDI

FILTERED IEC POWER ENTRY MODULE, IEC C14, MEDICAL, 10 A, 250 VAC, DPST, 1-POLE FUSE HOLDER

Search across all available documentation for this part.

Active

Astrodyne TDI

FILTERED IEC POWER ENTRY MODULE, IEC C14, MEDICAL, 10 A, 250 VAC, DPST, 1-POLE FUSE HOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	082SM.01000.00

Applications	General Purpose
Approval Agency	CE, SEMKO, cETLus
Configuration	Single Stage
Current	10 A
Filter Type	Single Phase
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	50 Hz
Mounting Type	Chassis Mount
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-25 °C
Termination Style	Quick Connect, IEC 320-C14
Voltage - Rated AC	250 V
Voltage - Rated AC (Phase to Phase)	1.45 kV

Part	Termination Style	Configuration	Filter Type	Operating Temperature [Min]	Operating Temperature [Max]	Current	Voltage - Rated AC (Phase to Phase)	Voltage - Rated AC	Mounting Type	Approval Agency	Applications	Frequency - Operating [Max]	Frequency - Operating [Min]
Astrodyne TDI 082SM.00100.00	IEC 320-C14 Quick Connect	Single Stage	Single Phase	-25 °C	40 °C	1 A	1.45 kV	250 V	Chassis Mount	CE cETLus SEMKO	General Purpose	60 Hz	50 Hz
Astrodyne TDI 082SM.00600.00	IEC 320-C14 Quick Connect	Single Stage	Single Phase	-25 °C	40 °C	6 A	1.45 kV	250 V	Chassis Mount	CE cETLus SEMKO	General Purpose	60 Hz	50 Hz
Astrodyne TDI 082SM.00300.00	IEC 320-C14 Quick Connect	Single Stage	Single Phase	-25 °C	40 °C	3 A	1.45 kV	250 V	Chassis Mount	CE cETLus SEMKO	General Purpose	60 Hz	50 Hz
Astrodyne TDI 082SM.01500.00	IEC 320-C14 Quick Connect	Single Stage	Single Phase	-25 °C	40 °C	15 A	1.45 kV	250 V	Chassis Mount	CE cETLus SEMKO	General Purpose	60 Hz	50 Hz
Astrodyne TDI 082SM.01000.00	IEC 320-C14 Quick Connect	Single Stage	Single Phase	-25 °C	40 °C	10 A	1.45 kV	250 V	Chassis Mount	CE cETLus SEMKO	General Purpose	60 Hz	50 Hz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 18.29

General part information

Single Phase EMC/EMI Line Filter 10 A 250V 50/60Hz Single Stage IEC 320-C14, Quick Connect
