IRM-90-24

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 24V 90W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 24V 90W

Technical Specifications

Parameters and characteristics for this part

Specification	IRM-90-24

Applications	Household Appliances, ITE (Commercial)
Approval Agency	cURus, CE, EAC, CB
Current - Output (Max) [Max]	3.75 A
Efficiency	93 %
Features	Universal Input
Line Regulation	0.5 %
Load Regulation	0.5 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	80 ¯C
Operating Temperature [Min]	-30 °C
Package / Case	4-DIP Module
Power (Watts)	90 W
Size / Dimension [x]	3.43 in
Size / Dimension [x]	87 mm
Size / Dimension [y]	52 mm
Size / Dimension [y]	2.05 in
Size / Dimension [z]	29.5 mm
Size / Dimension [z]	1.16 "
Type	Enclosed
Voltage - Output 1	24 V

Part	Features	Line Regulation	Mounting Type	Applications	Power (Watts)	Approval Agency	Package / Case	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Number of Outputs	Load Regulation	Efficiency	Voltage - Output 1	Current - Output (Max) [Max]	Type	Operating Temperature [Min]	Operating Temperature [Max]
MEAN WELL USA Inc. IRM-90-24	Universal Input	0.5 %	Through Hole	Household Appliances ITE (Commercial)	90 W	CB CE cURus EAC	4-DIP Module	29.5 mm	3.43 in	52 mm	87 mm	2.05 in	1.16 "	1	0.5 %	93 %	24 V	3.75 A	Enclosed	-30 °C	80 ¯C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 24V 3.75A 80 ~ 305 VAC, 113 ~ 431 VDC Input
