0192670050

Active

Molex

HEATSHRINK 1/16" X 4' YELLOW

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

0192670050

Active

Molex

HEATSHRINK 1/16" X 4' YELLOW

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	0192670050

Color	Yellow
Features	Flame Retardant
Inner Diameter - Recovered [diameter]	0.79 mm
Inner Diameter - Recovered [diameter]	0.031 in
Inner Diameter - Supplied [diameter]	0.063 in
Inner Diameter - Supplied [diameter]	1.6 mm
Length [x]	1.22 m
Length [x]	4 ft
Material	Polyolefin (PO)
Operating Temperature [Max]	135 °C
Operating Temperature [Min]	-55 °C
Recovered Wall Thickness	0.018 in
Recovered Wall Thickness	0.46 mm
Shrink Temperature	90 °C
Shrinkage Ratio	2 to 1
Type	Tubing, Flexible

019267 Series

Thin-Wall Multi-Purpose Heat Shrink Tubing, 1.60mm Inside Diameter (As Supplied), Black, 304.80m Length

...

Part	Shrinkage Ratio	Features	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Length [x]	Length [x]	Shrink Temperature	Recovered Wall Thickness	Recovered Wall Thickness	Color	Material	Type	Operating Temperature [Max]	Operating Temperature [Min]	Recovered Wall Thickness [custom]	Recovered Wall Thickness [custom]	Inner Diameter - Recovered	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Length	Length	Length	Length	Recovered Wall Thickness	Length [x]	Inner Diameter - Supplied [diameter]
Molex 0192670255	2 to 1	Flame Retardant	0.375 in	9.53 mm	1.22 m	4 ft	90 °C	0.76 mm	0.03 "	Black	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C
Molex 0192670469	2 to 1	Flame Retardant	0.125 in				90 °C			Black	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C	0.025 "	0.64 mm	3.18 mm	0.25 in	6.35 mm	1.25 "	0.104 '	31.75 mm
Molex 0192670053	2 to 1	Flame Retardant	0.031 in	0.79 mm			90 °C	0.46 mm		Red	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C				0.063 in	1.6 mm	6 "		152.4 mm	0.5 '	0.018 in
Molex 0192670050	2 to 1	Flame Retardant	0.031 in	0.79 mm	1.22 m	4 ft	90 °C	0.46 mm		Yellow	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C				0.063 in	1.6 mm					0.018 in
Molex 0192670206	2 to 1	Flame Retardant	0.187 in	4.75 mm			90 °C			Yellow	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C	0.025 "	0.64 mm		0.375 in	9.53 mm	6 "		152.4 mm	0.5 '
Molex 0192670345	2 to 1	Flame Retardant	1 in	25.4 mm	1.22 m	4 ft	90 °C	1.14 mm		Black	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C				2 in	50.8 mm					0.045 in
Molex 0192670496	2 to 1	Flame Retardant	0.062 in	1.57 mm	158.75 mm	0.521 ft	90 °C	0.51 mm		Black	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C				0.125 "	3.18 mm					0.02 in	6.25 in
Molex 0192670172	2 to 1	Flame Retardant	0.125 in				90 °C			White	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C	0.025 "	0.64 mm	3.18 mm	0.25 in	6.35 mm	6 "		152.4 mm	0.5 '
Molex 0192670597	2 to 1	Flame Retardant	0.062 in	1.57 mm			90 °C	0.51 mm		Black	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C				0.125 "	3.18 mm	6 "		152.4 mm	0.5 '	0.02 in
Molex 0192670084	2 to 1	Flame Retardant	0.046 in	1.17 mm			90 °C	0.51 mm		Blue	Polyolefin (PO)	Tubing Flexible	135 °C	-55 °C					0.093 in	6 "		152.4 mm	0.5 '	0.02 in		2.36 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	200	$ 0.26

Description

General part information

019267 Series

Thin-Wall Multi-Purpose Heat Shrink Tubing, 1.60mm Inside Diameter (As Supplied), Black, 304.80m Length
