10GX13 0091000

Obsolete

Belden Inc.

CABLE CAT6A 8COND 23AWG WHT 500'

Search across all available documentation for this part.

Obsolete

Belden Inc.

CABLE CAT6A 8COND 23AWG WHT 500'

Technical Specifications

Parameters and characteristics for this part

Specification	10GX13 0091000

Cable Type	Multi-Pair, Cat6a
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Bare
Conductor Strand	Solid
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	0.295 in
Jacket (Insulation) Diameter [diameter]	7.49 mm
Jacket (Insulation) Material	Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Length	1 ft, 1000 ft
Length	300 mm, 304.8 m
Length [x]	30.5 m, 152.4 m, 7.62 m
Length [x]	100 ft, 500 ', 25 ft
Number of Conductors	8
Ratings	UL Style CMP
Usage	Network
Voltage	300 V
Wire Gauge	23 AWG

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Ratings	Conductor Material	Length	Length	Usage	Wire Gauge	Length [x]	Length [x]	Conductor Strand	Cable Type	Conductor Insulation	Number of Conductors	Jacket (Insulation) Material	Features
Belden Inc. 10GX13 0091000	0.295 in	7.49 mm	300 V	UL Style CMP	Copper Bare	1 ft 1000 ft	300 mm 304.8 m	Network	23 AWG	7.62 m 30.5 m 152.4 m	25 ft 100 ft 500 '	Solid	Multi-Pair Cat6a	Fluorinated Ethylene-Propylene (FEP)	8	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	Rip Cord

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

8 (4 Pair) Conductor Multi-Pair, Cat6a Cable White 23 AWG 500.0' (152.4m)
