0395233902
ActiveMolex
TERM BLOCK PLUG 2POS 5MM
Deep-Dive with AI
Search across all available documentation for this part.
0395233902
ActiveMolex
TERM BLOCK PLUG 2POS 5MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0395233902 |
|---|---|
| Color | Black |
| Contact Material | Phosphor Bronze |
| Contact Mating Finish | Gold |
| Features | Retention Latches (Wire Side), Positions Stamped |
| Insulation Height | 1.02 in |
| Insulation Height | 25.91 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Plug Wire Entry | 90 ° |
| Positions Per Level | 2 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | 0.56 Nm |
| Torque - Screw | 5 Lb-In |
| Type | Plug, Female Sockets |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 26 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Strip Length | 5 mm |
039523 Series
...
| Part | Contact Material | Positions Per Level | Insulation Height | Insulation Height | Type | Wire Strip Length | Contact Mating Finish | Voltage - UL | Features | Mounting Type | Plug Wire Entry | Torque - Screw | Torque - Screw | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Material Flammability Rating | Pitch [x] | Pitch [x] | Color | Number of Positions | Number of Levels | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Phosphor Bronze | 2 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 2 | 1 | |
Molex | Phosphor Bronze | 11 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 11 | 1 | |
Molex | Phosphor Bronze | 3 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Free Hanging (In-Line) | 270 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 1 | |||
Molex | Phosphor Bronze | 16 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Tin | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 1 | 16 | |
Molex | Phosphor Bronze | 19 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 19 | 1 | |
Molex | Phosphor Bronze | 22 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Tin | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Black | 22 positions | 1 | |
Molex | Phosphor Bronze | 11 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Tin | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Green | 11 | 1 | |
Molex | Phosphor Bronze | 15 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Positions Stamped Retention Latches (Non-Wire Side) | Free Hanging (In-Line) | 270 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Green | 15 | 1 | |
Molex | Phosphor Bronze | 11 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Gold | 300 V | Positions Stamped Retention Latches (Wire Side) | Free Hanging (In-Line) | 90 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Green | 11 | 1 | |
Molex | Phosphor Bronze | 11 | 1.02 in | 25.91 mm | Plug Female Sockets | 5 mm | Tin | 300 V | Free Hanging (In-Line) | 270 ° | 0.56 Nm | 5 Lb-In | -40 °C | 105 ░C | Screw - Rising Cage Clamp | 12 AWG | 26 AWG | UL94 V-0 | 5 mm | 0.197 in | Green | 11 | 1 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 2592 | $ 1.14 | |
Description
General part information
039523 Series
2 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 90° Free Hanging (In-Line)
