BB-DR-UPS40

Obsolete

Advantech Corp

PS, UPS CHARGER, METAL, 40A, 24V

Search across all available documentation for this part.

Obsolete

Advantech Corp

PS, UPS CHARGER, METAL, 40A, 24V

Technical Specifications

Parameters and characteristics for this part

Specification	BB-DR-UPS40

Applications	Industrial Control, General Purpose
Form	Din Rail
Height [z]	4.929 in
Height [z]	125.2 mm
Size / Dimension [x]	3.937 in
Size / Dimension [x]	100 mm
Size / Dimension [y]	2.185 in
Size / Dimension [y]	55.5 mm
Type	Standby (No Regulation)
Voltage - Output	24 V

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Output	Applications	Type	Form	Height [z]	Height [z]
Advantech Corp BB-DR-UPS40	2.185 in	3.937 in	100 mm	55.5 mm	24 V	General Purpose Industrial Control	Standby (No Regulation)	Din Rail	4.929 in	125.2 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

PS, UPS CHARGER, METAL, 40A, 24V
