9437153001

Active

TE Connectivity Aerospace, Defense and Marine

HOOK-UP STRND 14AWG 1300V BLUE

Search across all available documentation for this part.

Active

TE Connectivity Aerospace, Defense and Marine

HOOK-UP STRND 14AWG 1300V BLUE

Technical Specifications

Parameters and characteristics for this part

Specification	9437153001

Cable Type	Hook-Up, Dual Wall
Conductor Material	Copper, Tinned
Conductor Strand [custom]	37
Conductor Strand [diameter]	0.0098 in
Jacket (Insulation) Diameter [diameter]	0.091 "
Jacket (Insulation) Diameter [diameter]	2.31 mm
Jacket (Insulation) Material	Polymer
Jacket (Insulation) Thickness	0.25 mm
Jacket (Insulation) Thickness	0.01 in
Jacket Color	Blue
Length	Enter Number of Feet in Order Quantity
Length [x]	500 m
Length [x]	1640.4 ft
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Spool Size	1640.4 ft
Spool Size	500 m
Voltage	1300 V
Wire Gauge	13.5 AWG

Part	Cable Type	Conductor Material	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage [Min]	Voltage [Max]	Operating Temperature	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Wire Gauge	Conductor Strand [diameter]	Conductor Strand [custom]	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Spool Size	Spool Size	Length [x]	Length [x]	Length	Voltage
TE Connectivity Aerospace, Defense and Marine 100G0111-1.50-6	Hook-Up Dual Wall	Copper Tinned	Polymer	0.082 in	2.08 mm	750 V	1300 V	125 °C	0.2 mm	0.008 in	Blue	15 AWG	0.0098 in	37	3281 ft	1000 m
TE Connectivity Aerospace, Defense and Marine 100G0111-0.40-4	Hook-Up Dual Wall		Polymer			750 V	1300 V				Yellow	22 AWG	0.0063 in				-55 °C	125 °C	19 Strands
TE Connectivity Aerospace, Defense and Marine 9437153001	Hook-Up Dual Wall	Copper Tinned	Polymer	0.091 "	2.31 mm				0.25 mm	0.01 in	Blue	13.5 AWG	0.0098 in	37			-55 °C	125 °C		1640.4 ft	500 m	500 m	1640.4 ft	Enter Number of Feet in Order Quantity	1300 V
TE Connectivity Aerospace, Defense and Marine 100G0111-2.00-0	Hook-Up Dual Wall	Copper Tinned	Polymer	0.093 in	2.36 mm	750 V	1300 V		0.2 mm	0.008 in	Black	13.5 AWG	0.0098 in	37			-55 °C	125 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

14 AWG Hook-Up, Dual Wall Wire 37/0.0098" Blue 1300V 1640.4' (500.0m)
