HE1G-21SM
ObsoleteIDEC
PUSH BUTTON SWITCH ROHS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HE1G-21SM
ObsoleteIDEC
PUSH BUTTON SWITCH ROHS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HE1G-21SM |
|---|---|
| Actuator Marking | No Marking |
| Circuit | 3PST-2NO/1NC |
| Current Rating (Amps) | 2 A, 3 A |
| Electrical Life | 100000 Cycles |
| Ingress Protection | IP66 |
| Mechanical Life | 100000 Cycles |
| Mounting Type | Free Hanging |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -25 °C |
| Switch Function | Off-On-Off |
| Termination Style | Connector |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 30 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| LCSC | N/A | 1 | $ 0.00 | |
Description
General part information
HE1G Series
Pushbutton Switch 3PST-2NO/1NC Free Hanging
