2SP0320V2A0-12

Active

Power Integrations

IGBT DRIVER, 14.5V-15.5V, MODULE ROHS COMPLIANT: NO

Search across all available documentation for this part.

Active

Power Integrations

IGBT DRIVER, 14.5V-15.5V, MODULE ROHS COMPLIANT: NO

Technical Specifications

Parameters and characteristics for this part

Specification	2SP0320V2A0-12

Channel Type	Independent
Current - Peak Output (Source, Sink) [custom]	20 A
Current - Peak Output (Source, Sink) [custom]	20 A
Driven Configuration	Half-Bridge
Gate Type	IGBT
High Side Voltage - Max (Bootstrap) [Max]	1200 V
Mounting Type	Surface Mount
Number of Drivers	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Rise / Fall Time (Typ) [custom]	7 ns
Rise / Fall Time (Typ) [custom]	25 ns
Supplier Device Package	Module
Voltage - Supply [Max]	15.5 V
Voltage - Supply [Min]	14.5 V

Part	Supplier Device Package	Voltage - Supply [Min]	Voltage - Supply [Max]	Number of Drivers	High Side Voltage - Max (Bootstrap) [Max]	Channel Type	Driven Configuration	Operating Temperature [Max]	Operating Temperature [Min]	Gate Type	Package / Case	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Current - Peak Output (Source, Sink) [custom]	Current - Peak Output (Source, Sink) [custom]	Mounting Type
Power Integrations 2SP0320V2A0-12	Module	14.5 V	15.5 V	2	1200 V	Independent	Half-Bridge	85 °C	-40 °C	IGBT	Module	7 ns	25 ns	20 A	20 A	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Half-Bridge Gate Driver IC Module
