TRI 15-2423
ActiveTraco Power
DC DC CONVERTER +/-15V 15W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TRI 15-2423
ActiveTraco Power
DC DC CONVERTER +/-15V 15W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TRI 15-2423 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, cURus |
| Current - Output (Max) | 500 mA |
| Current - Output (Max) | 500 mA |
| Efficiency | 89 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 5-DIP Module |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 2 in |
| Size / Dimension [x] | 50.8 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [z] | 12 mm |
| Size / Dimension [z] | 0.47 " |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 8 kV |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 71.70 | |
| 10 | $ 64.42 | |||
| 25 | $ 62.29 | |||
| 50 | $ 60.73 | |||
| 100 | $ 59.21 | |||
| 250 | $ 52.25 | |||
Description
General part information
TRI 15 Series
Isolated Module DC DC Converter 2 Output 15V -15V 500mA, 500mA 18V - 36V Input
