MS27467T13F8S

Active

Corsair

PLUG STRAIGHT CABLE

Search across all available documentation for this part.

Active

Corsair

PLUG STRAIGHT CABLE

Technical Specifications

Parameters and characteristics for this part

Specification	MS27467T13F8S

Applications	Military, Aerospace
Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	1.27 µm
Contact Finish Thickness - Mating	50 µin
Contact Material	Copper Alloy
Current Rating (Amps)	7.5 A
Fastening Type	Bayonet Lock
Features	Coupling Nut
Grade	Military
Ingress Protection	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	8
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Orientation	N
Primary Material	Metal
Qualification	MIL-DTL-38999 Series I
Shell Finish	Nickel
Shell Material	Aluminum Alloy
Shell Size - Insert	13-8
Shell Size, MIL	B
Shielding	Shielded
Termination	Crimp

Part	Termination	Grade	Current Rating (Amps)	Primary Material	Number of Positions	Applications	Shell Finish	Contact Finish - Mating	Mounting Type	Connector Type	Material Flammability Rating	Ingress Protection	Shell Size, MIL	Color	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Features	Contact Material	Orientation	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Material	Insert Material	Qualification	Shielding
Corsair MS27467T13F8S	Crimp	Military	7.5 A	Metal	8	Aerospace Military	Nickel	Gold	Free Hanging (In-Line)	Female Sockets Plug	UL94 V-0	IP67	B	Silver	Bayonet Lock	-65 ░C	200 °C	13-8	Coupling Nut	Copper Alloy	N	1.27 µm	50 µin	Aluminum Alloy	Thermoplastic	MIL-DTL-38999 Series I	Shielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

8 Position Circular Connector Plug, Female Sockets Crimp
