3403.0284.23

Active

SCHURTER Inc.

FUSE CHIP SLOW BLOW ACTING 10A 250V SMD SOLDER PAD 15.4 X 5.35 X 5.35MM CERAMIC T/R AUTOMOTIVE AEC-Q200 UL/VDE

Search across all available documentation for this part.

Active

SCHURTER Inc.

FUSE CHIP SLOW BLOW ACTING 10A 250V SMD SOLDER PAD 15.4 X 5.35 X 5.35MM CERAMIC T/R AUTOMOTIVE AEC-Q200 UL/VDE

Technical Specifications

Parameters and characteristics for this part

Specification	3403.0284.23

Approval Agency	CQC, VDE, cURus
Breaking Capacity @ Rated Voltage	1.5 kA
Current Rating (Amps)	10 A
Fuse Type	Board Mount
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	2-SMD, Square End Block
Response Time	Slow Blow
Size / Dimension [x]	0.606 "
Size / Dimension [x]	15.4 mm
Size / Dimension [y]	5.35 mm
Size / Dimension [y]	0.211 "
Size / Dimension [z]	0.211 in
Size / Dimension [z]	5.35 mm
Voltage Rating - AC	250 V
Voltage Rating - DC	125 VDC

Part	Mounting Type	Voltage Rating - DC	Response Time	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Breaking Capacity @ Rated Voltage	Approval Agency	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Voltage Rating - AC	Fuse Type
SCHURTER Inc. 3403.0284.23	Surface Mount	125 VDC	Slow Blow	10 A	-55 °C	125 °C	1.5 kA	CQC cURus VDE	2-SMD Square End Block	5.35 mm	0.606 "	15.4 mm	0.211 in	0.211 "	5.35 mm	250 V	Board Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 A 250 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
