D2450PG

Active

Sensata-Crydom

SSR RELAY SPST-NO 50A 24-280V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 50A 24-280V

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Termination Style	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Load [Min]	Voltage - Load [Max]	Load Current	Package / Case
Sensata-Crydom D2450-10	Chassis Mount	CE CSA TUV UL	-40 °C	80 C	AC	Screw Terminal	32 V	3 V	24 V	280 V	50 A	Hockey Puck
Sensata-Crydom D2450K	Chassis Mount	CE CSA TUV UL	-40 °C	80 C	AC Zero Cross	Screw Terminal	32 V	3 V	24 V	280 V	50 A	Hockey Puck
Sensata-Crydom D2450H-B	Chassis Mount	CE CSA TUV UL	-40 °C	80 C	AC Zero Cross	Screw Terminal	32 V	3 V	24 V	280 V	50 A	Hockey Puck
Sensata-Crydom D2450PG	Chassis Mount	CE CSA TUV UL	-40 °C	80 C	AC Zero Cross	Screw Terminal	32 V	3 V	24 V	280 V	50 A	Hockey Puck

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) Hockey Puck

Technical documentation and resources
