DWN3.50BK150

Active

Techflex

SELF WRAP 3.5" X 150' BLACK

Search across all available documentation for this part.

Active

Techflex

SELF WRAP 3.5" X 150' BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	DWN3.50BK150

Abrasion Protection	Abrasion Resistant
Color	Black
Diameter - Inside, Non-Expanded [diameter]	88.9 mm
Diameter - Inside, Non-Expanded [diameter]	3.5 in
Environment Protection	Environment Resistant, UV Resistant
Features	Hook and Loop Closure Strip, Clean Cut, Chemical Resistant
Length	45.72 m
Length	150 ft
Liquid Protection	Fluid Resistant, Gasoline Resistant, Salt Water Resistant
Material	Nylon, Polyamide (PA), Halogen Free
Operating Temperature [Max]	93.3 °C
Operating Temperature [Min]	-51.1 °C
Type	Self Wrap
Type Attributes	Split Flexible Tube
Wall Thickness	0.66 mm
Wall Thickness	0.026 in

Part	Abrasion Protection	Diameter - Inside, Non-Expanded [diameter]	Diameter - Inside, Non-Expanded [diameter]	Type Attributes	Type	Environment Protection	Material	Length	Length	Features	Operating Temperature [Min]	Operating Temperature [Max]	Color	Wall Thickness	Wall Thickness	Liquid Protection
Techflex DWN3.50BK150	Abrasion Resistant	88.9 mm	3.5 in	Split Flexible Tube	Self Wrap	Environment Resistant UV Resistant	Halogen Free Nylon Polyamide (PA)	45.72 m	150 ft	Chemical Resistant Clean Cut Hook and Loop Closure Strip	-51.1 °C	93.3 °C	Black	0.66 mm	0.026 in	Fluid Resistant Gasoline Resistant Salt Water Resistant

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 1054.52

General part information

Self Wrap X 150' (45.72m) Black
