PXP9052/08/S

Active

BULGIN LIMITED

CIRCULAR CONNECTOR, BUCCANEER 9000 SERIES, PANEL MOUNT RECEPTACLE, 8 CONTACTS, CRIMP SOCKET

Search across all available documentation for this part.

Active

BULGIN LIMITED

CIRCULAR CONNECTOR, BUCCANEER 9000 SERIES, PANEL MOUNT RECEPTACLE, 8 CONTACTS, CRIMP SOCKET

Technical Specifications

Parameters and characteristics for this part

Specification	PXP9052/08/S

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Silver
Contact Material	Copper Alloy
Current Rating (Amps)	80 A, 13 A
Ingress Protection	IP68 - Dust Tight, Waterproof
Material Flammability Rating	UL94 V-0
Mounting Feature	Flange
Number of Positions	8
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Polyoxymethylene (POM), Acetal
Shielding	Unshielded
Termination	Crimp

Part	Contact Material	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Orientation	Contact Finish - Mating	Ingress Protection	Color	Mounting Feature	Shell Material	Number of Positions	Termination	Primary Material	Current Rating (Amps)	Shielding	Features	Mounting Type	Fastening Type	Cable Opening [diameter]	Cable Opening [diameter]
BULGIN LIMITED PXP9052/08/S	Copper Alloy	UL94 V-0	-55 °C	125 °C	Receptacle Female Sockets	Keyed	Silver	IP68 - Dust Tight Waterproof	Black	Flange	Acetal Polyoxymethylene (POM)	8	Crimp	Plastic	13 A 80 A	Unshielded
BULGIN LIMITED PXP9011/08/S/1	Copper Alloy	UL94 V-0	-55 °C	125 °C	Receptacle Female Sockets	Keyed	Silver	IP68 - Dust Tight Waterproof	Black		Acetal Polyoxymethylene (POM)	8	Crimp	Plastic	13 A 80 A	Unshielded	Backshell	Free Hanging (In-Line)	Bayonet Lock	48.26 mm	1.9 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 505.74
Newark	Each	1	$ 821.32
		200	$ 698.12
TME	N/A	10	$ 565.91

General part information

8 (Power) Position Circular Connector Receptacle, Female Sockets Crimp
