K2D002UCH

Active

SQUARE D BY SCHNEIDER ELECTRIC

SWITCH ROTARY 2POS

Search across all available documentation for this part.

Active

SQUARE D BY SCHNEIDER ELECTRIC

SWITCH ROTARY 2POS

Technical Specifications

Parameters and characteristics for this part

Specification	K2D002UCH

Actuator Type	Knob
Angle of Throw	45 °
Contact Timing	Not Specified
Index Stops	Fixed
Number of Decks [custom]	1
Number of Poles per Deck	3
Number of Positions	2
Panel Cutout Dimensions [diameter]	22 mm
Termination Style	Screw Terminal

Part	Termination Style	Number of Positions	Number of Poles per Deck	Index Stops	Number of Decks [custom]	Angle of Throw	Panel Cutout Dimensions [diameter]	Actuator Type	Contact Timing
SQUARE D BY SCHNEIDER ELECTRIC K2D002UCH	Screw Terminal	2	3	Fixed	1	45 °	22 mm	Knob	Not Specified

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 144.34

General part information

Rotary Switch 2 Position 3PDT AC Panel Mount
