SG901-1066 ANTENNA
ActiveSagrad Inc.
RF ANT 2.4GHZ PCB TRACE IPEX SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SG901-1066 ANTENNA |
|---|---|
| Antenna Type | PCB Trace |
| Frequency Range [Max] | 2.49 GHz |
| Frequency Range [Min] | 2.4 GHz |
| Gain | 3.8 dBi |
| Height (Max) [Max] | 0.087 in |
| Height (Max) [Max] | 2.2 mm |
| Mounting Type | Surface Mount |
| Number of Bands | 1 |
| Termination | IPEX MHF1, U.FL (UMCC) |
| VSWR | 2 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 5.15 | |
| 10 | $ 4.66 | |||
| 25 | $ 4.44 | |||
| 100 | $ 3.85 | |||
| 300 | $ 3.81 | |||
Description
General part information
SG901 Series
RF ANTENNA PCB Trace U.FL (UMCC), IPEX MHF1 Surface Mount
