1952607

Active

Phoenix Contact

BARRIER STRIP TERMINAL BLOCK, 8A, 1 ROW(S), 1 DECK(S), ROHS COMPLIANT

Search across all available documentation for this part.

Active

Phoenix Contact

BARRIER STRIP TERMINAL BLOCK, 8A, 1 ROW(S), 1 DECK(S), ROHS COMPLIANT

Technical Specifications

Parameters and characteristics for this part

Specification	1952607

Color	Black
Contact Mating Finish	Tin
Contact Tail Length	0.055 in
Contact Tail Length	1.4 mm
Current - IEC	8 A
Current - UL	8 A
Features	Locking Ramp
Header Orientation	Vertical
Housing Material	Liquid Crystal Polymer (LCP)
Insulation Height [z]	0.524 in
Insulation Height [z]	13.3 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Levels	2
Number of Positions	24
Pitch [x]	3.5 mm
Pitch [x]	0.138 in
Positions Per Level	12
Termination Style	Solder
Type	Header, Male Pins, Shrouded (4 Side)
Voltage - IEC	250 V
Voltage - UL	150 V

Pluggable Terminal Blocks 12 Pos 3.5mm pitch Through Hole Header

Part	Contact Mating Finish	Current - IEC	Color	Voltage - UL	Current - UL	Positions Per Level	Pitch [x]	Pitch [x]	Material Flammability Rating	Type	Insulation Height [z]	Insulation Height [z]	Voltage - IEC	Contact Tail Length	Contact Tail Length	Header Orientation	Number of Levels	Housing Material	Features	Mounting Type	Termination Style	Number of Positions
Phoenix Contact 1952607	Tin	8 A	Black	150 V	8 A	12	3.5 mm	0.138 in	UL94 V-0	Header Male Pins Shrouded (4 Side)	0.524 in	13.3 mm	250 V	0.055 in	1.4 mm	Vertical	2	Liquid Crystal Polymer (LCP)	Locking Ramp	Through Hole	Solder	24
Phoenix Contact 1952717	Tin	8 A	Black	150 V	8 A	14	3.5 mm	0.138 in	UL94 V-0	Header Male Pins Shrouded (4 Side)	0.524 in	13.3 mm	250 V	0.102 in	2.6 mm	Vertical	2	Liquid Crystal Polymer (LCP)	Locking Ramp	Through Hole	Solder	28

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 11.47
Sager	N/A	50	$ 13.51
		100	$ 13.02

General part information

Pluggable Terminal Blocks 12 Pos 3.5mm pitch Through Hole Header
