M20-7861546

Active

Harwin Inc.

CONNECTOR, RCPT, 15POS, 2.54MM, 1ROW

Search across all available documentation for this part.

Active

Harwin Inc.

CONNECTOR, RCPT, 15POS, 2.54MM, 1ROW

Technical Specifications

Parameters and characteristics for this part

Specification	M20-7861546

Applications	General Purpose
Connector Type	Receptacle, Bottom or Top Entry
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.295 in
Insulation Height	7.5 mm
Insulation Material	Nylon 6T, Polyamide (PA6T)
Mated Stacking Heights	10.04 mm, 11.63 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	15
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Termination	Solder

Part	Number of Positions	Pitch - Mating	Pitch - Mating	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish - Mating	Contact Shape	Current Rating (Amps)	Termination	Contact Finish - Post	Contact Material	Number of Positions Loaded	Number of Rows	Mated Stacking Heights	Mounting Type	Contact Type	Material Flammability Rating	Insulation Height	Insulation Height	Fastening Type	Applications	Insulation Material	Number of Positions
Harwin Inc. M20-7861642	16	0.1 in	2.54 mm	Black	-40 °C	105 ░C	Receptacle Bottom or Top Entry	Gold	Square	3 A	Solder	Tin	Phosphor Bronze	All	1	10.04 mm 11.63 mm	Surface Mount	Female Socket	UL94 V-0	0.295 in	7.5 mm	Push-Pull	General Purpose	Nylon 6T Polyamide (PA6T)
Harwin Inc. M20-7860346		0.1 in	2.54 mm	Black	-40 °C	105 ░C	Receptacle Bottom or Top Entry		Square	3 A	Solder	Tin	Phosphor Bronze	All	1	10.04 mm 11.63 mm	Surface Mount	Female Socket	UL94 V-0	0.295 in	7.5 mm	Push-Pull	General Purpose	Nylon 6T Polyamide (PA6T)
Harwin Inc. M20-7860546		0.1 in	2.54 mm	Black	-40 °C	105 ░C	Receptacle Bottom or Top Entry		Square	3 A	Solder	Tin	Phosphor Bronze	All	1	10.04 mm 11.63 mm	Surface Mount	Female Socket	UL94 V-0	0.295 in	7.5 mm	Push-Pull	General Purpose	Nylon 6T Polyamide (PA6T)
Harwin Inc. M20-7861546		0.1 in	2.54 mm	Black	-40 °C	105 ░C	Receptacle Bottom or Top Entry		Square	3 A	Solder	Tin	Phosphor Bronze	All	1	10.04 mm 11.63 mm	Surface Mount	Female Socket	UL94 V-0	0.295 in	7.5 mm	Push-Pull	General Purpose	Nylon 6T Polyamide (PA6T)	15

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

15 Position Receptacle, Bottom or Top Entry Connector 0.100" (2.54mm) Surface Mount Tin
