AZ943-1AH-24DE

Active

American Zettler

RELAY GEN PURPOSE SPST 15A 24V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AZ943-1AH-24DE

Active

American Zettler

RELAY GEN PURPOSE SPST 15A 24V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AZ943-1AH-24DE

Approval Agency	TUV, VDE, UL, cUR
Coil Current	15 mA
Coil Insulation	Class B
Coil Resistance	1.6 kOhms
Coil Type	Non Latching
Coil Voltage	24 VDC
Contact Form	SPST-NO (1 Form A)
Contact Material	Silver Tin Oxide (AgSnO)
Contact Rating (Current)	15 A
Load - Max Switching	2770 VA, 300 W
Mounting Type	Through Hole
Must Operate Voltage	18 VDC
Must Release Voltage	2.4 VDC
Operate Time	10 ms
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	5 ms
Seal Rating	Sealed - Fully
Switching Voltage	277 VAC, 30 VDC
Termination Style	PC Pin

AZ943-1A Series

Part	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Relay Type	Contact Rating (Current)	Termination Style	Must Release Voltage	Coil Insulation	Release Time	Operate Time	Seal Rating	Coil Resistance	Coil Voltage	Coil Current	Switching Voltage	Load - Max Switching	Approval Agency	Contact Form	Coil Type	Must Operate Voltage	Mounting Type
American Zettler AZ943-1AH-5D	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	0.5 VDC	Class B	5 ms	10 ms	Sealed - Flux Protection	70 Ohms	5 VDC	71.4 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	3.8 VDC	Through Hole
American Zettler AZ943-1AH-48DE	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	4.8 VDC	Class B	5 ms	10 ms	Sealed - Fully	6.4 kOhms	48 VDC	7.5 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	36 VDC	Through Hole
American Zettler AZ943-1AH-18DEFG	110 °C	-40 °C	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	1.8 VDC	Class F	5 ms	10 ms	Sealed - Fully	900 Ohms	18 VDC	20 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	13.5 VDC	Through Hole
American Zettler AZ943-1AH-24D	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	2.4 VDC	Class B	5 ms	10 ms	Sealed - Flux Protection	1.6 kOhms	24 VDC	15 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	18 VDC	Through Hole
American Zettler AZ943-1AH-15DF	110 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	1.5 VDC	Class F	5 ms	10 ms	Sealed - Flux Protection		15 VDC		30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching		Through Hole
American Zettler AZ943-1AH-24DE	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	2.4 VDC	Class B	5 ms	10 ms	Sealed - Fully	1.6 kOhms	24 VDC	15 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	18 VDC	Through Hole
American Zettler AZ943-1AH-12DE	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	1.2 VDC	Class B	5 ms	10 ms	Sealed - Fully	400 Ohms	12 VDC	30 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	9 VDC	Through Hole
American Zettler AZ943-1AH-24DEG	90 °C	-40 °C	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	2.4 VDC	Class B	5 ms	10 ms	Sealed - Fully	1.6 kOhms	24 VDC	15 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	18 VDC	Through Hole
American Zettler AZ943-1AH-6DE	90 °C	-40 °C	Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	0.6 VDC	Class B	5 ms	10 ms	Sealed - Fully	100 Ohms		60 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	4.5 VDC	Through Hole
American Zettler AZ943-1AH-5DEG	90 °C	-40 °C	Gold (Au) Silver Tin Oxide (AgSnO)	General Purpose	15 A	PC Pin	0.5 VDC	Class B	5 ms	10 ms	Sealed - Fully	70 Ohms	5 VDC	71.4 mA	30 VDC 277 VAC	300 W 2770 VA	cUR TUV UL VDE	SPST-NO (1 Form A)	Non Latching	3.8 VDC	Through Hole

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 0.87
		20	$ 0.82
		40	$ 0.69
		100	$ 0.65
		260	$ 0.58
		500	$ 0.55
		1000	$ 0.51
		5000	$ 0.49

Description

General part information

AZ943-1A Series

General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
