AM200QB-4824SH22-NZ
Activeaimtec
DC DC CONVERTER 24V 202W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM200QB-4824SH22-NZ
Activeaimtec
DC DC CONVERTER 24V 202W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM200QB-4824SH22-NZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 8.4 A |
| Efficiency | 91 % |
| Features | Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Quarter Brick |
| Power (Watts) | 200 W |
| Size / Dimension [x] | 2.43 in |
| Size / Dimension [x] | 61.8 mm |
| Size / Dimension [y] | 40.2 mm |
| Size / Dimension [y] | 1.58 in |
| Size / Dimension [z] | 0.5 in |
| Size / Dimension [z] | 12.7 mm |
| Supplier Device Package | Quarter Brick |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 2250 VDC |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AM200QB Series
Isolated Module DC DC Converter 1 Output 24V 8.4A 18V - 75V Input
