S1C17W22F101100
ActiveEpson Electronics America Inc-Semiconductor Div
IC MCU 16BIT 64KB FLASH 128TQFP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
S1C17W22F101100
ActiveEpson Electronics America Inc-Semiconductor Div
IC MCU 16BIT 64KB FLASH 128TQFP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | S1C17W22F101100 |
|---|---|
| Connectivity | IrDA, UART/USART, I2C, SPI |
| Core Size | 16-Bit |
| Mounting Type | Surface Mount |
| Number of I/O | 41 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Oscillator Type | Internal |
| Package / Case | 128-TQFP |
| Peripherals | RFC, PWM, WDT, LCD |
| Program Memory Size | 64 KB |
| Program Memory Type | FLASH |
| RAM Size | 4K x 8 |
| Speed | 4.2 MHz |
| Voltage - Supply (Vcc/Vdd) [Max] | 3.6 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 1.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 8.49 | |
| 10 | $ 5.84 | |||
| 25 | $ 5.16 | |||
| 80 | $ 4.50 | |||
| 230 | $ 4.05 | |||
| 440 | $ 3.83 | |||
| 945 | $ 3.62 | |||
| 2400 | $ 3.48 | |||
Description
General part information
S1C17W22 Series
S1C17 - Microcontroller IC 16-Bit 4.2MHz 64KB (64K x 8) FLASH 128-TQFP (14x14)
