1800103

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKKDSN 1,5/3-5,08 BK

Search across all available documentation for this part.

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKKDSN 1,5/3-5,08 BK

Technical Specifications

Parameters and characteristics for this part

Specification	1800103

Color	Black
Contact Material - Plating	Copper Alloy - Tin Plated
Current	10 A
Features	Interlocking (Side)
Housing Material	Polyamide (PA), Nylon
Mating Orientation	Horizontal with Board
Mounting Type	Through Hole
Number of Levels	2
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Pitch [x]	0.2 in
Pitch [x]	5.08 mm
Positions Per Level	3
Torque - Screw [Max]	0.6 Nm
Torque - Screw [Max]	5.3 Lb-In
Torque - Screw [Min]	4.4 Lb-In
Torque - Screw [Min]	0.5 Nm
Voltage	300 V
Wire Gauge [Max]	30 AWG
Wire Gauge [Min]	14 AWG
Wire Termination	Screw, Tension Sleeve, Clamping Yoke

Fixed Terminal Blocks MKKDSN 1,5/3-5,08 BK

Part	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Features	Contact Material - Plating	Current	Wire Gauge [Min]	Wire Gauge [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Wire Termination	Color	Mating Orientation	Number of Levels	Voltage	Positions Per Level	Pitch [x]	Pitch [x]	Housing Material
Phoenix Contact 1800103	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Interlocking (Side)	Copper Alloy - Tin Plated	10 A	14 AWG	30 AWG	100 °C	-40 °C	Through Hole	Clamping Yoke Screw Tension Sleeve	Black	Horizontal with Board	2	300 V	3	0.2 in	5.08 mm	Polyamide (PA) Nylon

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fixed Terminal Blocks MKKDSN 1,5/3-5,08 BK

Technical documentation and resources
