BD2FF
ActiveHammond Manufacturing
PWR XFMR LAMINATED 20VA CHAS MT
Deep-Dive with AI
Search across all available documentation for this part.
BD2FF
ActiveHammond Manufacturing
PWR XFMR LAMINATED 20VA CHAS MT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BD2FF |
|---|---|
| Center Tap | False |
| Current - Output (Max) [Max] | 1.11 A |
| Height - Seated (Max) [Max] [z] | 50.29 mm |
| Mounting Type | Chassis Mount |
| Power - Max [Max] | 20 VA |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Single |
| Size / Dimension [x] | 59.18 mm |
| Size / Dimension [y] | 59.44 mm |
| Termination Style | Wire Leads, Quick Connect |
| Type | Laminated Core |
| Voltage - Primary | 120 V |
| Voltage - Secondary (Full Load) | 18 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 19.03 | |
| 10 | $ 16.19 | |||
| 25 | $ 15.43 | |||
| 50 | $ 15.24 | |||
Description
General part information
BD2F Series
PWR XFMR LAMINATED 20VA CHAS MT
Documents
Technical documentation and resources
No documents available
