STL-3-250-3-01

Active

Essentra Access Solutions

CBL CLIP TWIST LOCK NAT FIR TREE

Search across all available documentation for this part.

Active

Essentra Access Solutions

CBL CLIP TWIST LOCK NAT FIR TREE

Technical Specifications

Parameters and characteristics for this part

Specification	STL-3-250-3-01

Color	Natural
Height [z]	23.9 mm
Height [z]	0.941 in
Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-2
Mounting Type	Fir Tree
Opening Size [Max] [custom]	0.301 in
Opening Size [Max] [custom]	7.65 mm
Opening Size [Min] [custom]	0.201 in
Opening Size [Min] [custom]	5.11 mm
Panel Hole Size	0.311 in
Panel Hole Size	7.9 mm
Panel Thickness	0.25 "
Panel Thickness	6.35 mm
Type	Clip, Twist Lock

Part	Material Flammability Rating	Color	Height [z]	Height [z]	Material	Panel Thickness	Panel Thickness	Opening Size [Max] [custom]	Opening Size [Min] [custom]	Opening Size [Max] [custom]	Opening Size [Min] [custom]	Type	Mounting Type	Panel Hole Size	Panel Hole Size
Essentra Access Solutions STL-3-250-3-01	UL94 V-2	Natural	23.9 mm	0.941 in	Polyamide (PA66) Nylon 6/6	0.25 "	6.35 mm	0.301 in	0.201 in	7.65 mm	5.11 mm	Clip Twist Lock	Fir Tree	0.311 in	7.9 mm
Essentra Access Solutions STL-3-250-8-01	UL94 V-2	Natural	31.8 mm	1.252 in	Polyamide (PA66) Nylon 6/6	0.25 "	6.35 mm	0.301 in	0.201 in	7.65 mm	5.11 mm	Clip Twist Lock	Fir Tree	0.311 in	7.9 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Clip, Twist Lock Natural Fir Tree 0.201" ~ 0.301" (5.11mm ~ 7.65mm)

Technical documentation and resources
