RER-S4C-A230

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 5A 230V

Search across all available documentation for this part.

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 5A 230V

Technical Specifications

Parameters and characteristics for this part

Part	Switching Voltage [Max]	Contact Rating (Current)	Must Operate Voltage	Contact Material	Release Time	Relay Type	Coil Current	Coil Resistance	Coil Type	Features	Coil Voltage	Must Release Voltage	Contact Form	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Operate Time
Dinkle Corporation, USA RER-S4C-A230	30 VDC 250 VAC	5 A	184 VAC	Silver Nickel (AgNi)	20 ms	General Purpose	5.5 mA	4.43 kOhms	Non Latching	Lighted Indicator	230 VAC	69 VAC	4PDT (4 Form C)	70 °C	-55 °C	Socketable	20 ms
Dinkle Corporation, USA RER-S4C-A120	30 VDC 250 VAC	5 A	96 VAC	Silver Nickel (AgNi)	20 ms	General Purpose	9.2 mA	4.43 kOhms	Non Latching	Lighted Indicator	120 VAC	36 VAC	4PDT (4 Form C)	70 °C	-55 °C	Socketable	20 ms
Dinkle Corporation, USA RER-S4C-D24	30 VDC 250 VAC	5 A	18 VDC	Silver Nickel (AgNi)	20 ms	General Purpose	36.9 mA	640 Ohms	Non Latching	Lighted Indicator	24 VDC	2.4 VDC	4PDT (4 Form C)	70 °C	-55 °C	Socketable	20 ms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay 4PDT (4 Form C) 230VAC Coil Socketable
