12735/3/1

Active

BULGIN LIMITED

CIRCULAR CONNECTOR INSERT, BUCCANEER MINI SERIES, 3 CONTACTS, SOCKET, SOLDER

Search across all available documentation for this part.

Active

BULGIN LIMITED

CIRCULAR CONNECTOR INSERT, BUCCANEER MINI SERIES, 3 CONTACTS, SOCKET, SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	12735/3/1

Contact Shape	Circular
Contact Type	Solder Cup
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Nylon, Polyamide (PA)
Material Flammability Rating	UL94 V-0
Note	Note: Contacts Not Included; Insert Only, Requires Shell
Number of Positions [custom]	3
Number of Positions [custom]	1
Number of Positions [custom]	2
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Orientation	Keyed
Shielding	Unshielded
Type	For Female Sockets

Part	Ingress Protection	Insert Material	Operating Temperature [Min]	Operating Temperature [Max]	Orientation	Shielding	Number of Positions [custom]	Number of Positions [custom]	Number of Positions [custom]	Type	Contact Type	Material Flammability Rating	Note	Contact Shape
BULGIN LIMITED 12735/3/1	IP68 - Dust Tight Waterproof	Nylon Polyamide (PA)	-20 C	70 °C	Keyed	Unshielded	3	1	2	For Female Sockets	Solder Cup	UL94 V-0	Note: Contacts Not Included; Insert Only Requires Shell	Circular
BULGIN LIMITED 12735/3	IP68 - Dust Tight Waterproof	Nylon Polyamide (PA)	-20 C	70 °C	Keyed	Unshielded	3	1	2	For Female Sockets	Crimp	UL94 V-0	Note: Contacts Not Included; Insert Only Requires Shell	Circular

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3-Pin solder socket contact carrier insert for Mini Buccaneer® series connectors
