4-1393809-0

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 6PST 2A 48V

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 6PST 2A 48V

Technical Specifications

Parameters and characteristics for this part

Part	Operate Time	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Coil Current	Coil Resistance	Release Time	Coil Voltage	Relay Type	Coil Type	Mounting Type	Contact Form	Must Operate Voltage	Contact Rating (Current)	Switching Voltage	Contact Material	Load - Max Switching
TE Connectivity Potter & Brumfield Relays 1393809-8	7.5 ms	-40 °C	70 °C	Plug In	27 mA	890 Ohms	3 ms	24 VDC	General Purpose	Non Latching	Socketable
TE Connectivity Potter & Brumfield Relays 3-1393809-8	7.5 ms	-40 °C	70 °C	Plug In	15 mA	3.2 kOhms	3 ms	48 VDC	General Purpose	Non Latching	Socketable	4PDT (4 Form C)	30 VDC	200 mA	30 VAC 36 VDC	Gold (Au)
TE Connectivity Potter & Brumfield Relays 2-1393809-1	7.5 ms	-40 °C	70 °C	Plug In	18.8 mA	1.7 kOhms	3 ms	32 VDC	General Purpose	Non Latching	Socketable	4PDT (4 Form C)	22.6 VDC	200 mA	30 VAC 36 VDC	Gold (Au)
TE Connectivity Potter & Brumfield Relays 4-1393809-0	7.5 ms	-40 °C	70 °C	Plug In	15 mA	3.2 kOhms	3 ms	48 VDC	General Purpose	Non Latching	Socketable	6PST-NO (6 Form A)	37 VDC	2 A	125 VAC 150 VDC	Gold (Au) Silver (Ag)	250 VA 300 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	20	$ 161.28

General part information

General Purpose Relay 6PST-NO (6 Form A) Socketable
