A1309LUATN-9-T
ActiveAllegro MicroSystems
LINEAR HALL SENSOR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | A1309LUATN-9-T |
|---|---|
| Axis | Single |
| Bandwidth | 20 kHz |
| Current - Output (Max) [Max] | 10 mA |
| Current - Supply (Max) [Max] | 11.5 mA |
| Mounting Type | Through Hole |
| Output Type | Analog Voltage |
| Package / Case | 3-SSIP |
| Supplier Device Package | 3-SIP |
| Technology | Hall Effect |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 12000 | $ 0.69 | |
Description
General part information
A1309 Series
Hall Effect Sensor Single Axis 3-SIP
