UCC28711EVM-160

Active

Texas Instruments

MODULE EVAL FOR UCC28711-160

Search across all available documentation for this part.

Active

Texas Instruments

MODULE EVAL FOR UCC28711-160

Technical Specifications

Parameters and characteristics for this part

Part	Fault Protection	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Frequency - Switching [Max]	Frequency - Switching [Min]	Voltage - Start Up	Output Isolation	Package / Case [custom]	Package / Case	Package / Case [custom]	Package / Case	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Topology	Mounting Type	Regulator Topology	Voltage - Output	Main Purpose	Frequency - Switching	Board Type	Power - Output	Current - Output	Outputs and Type	Outputs and Type	Supplied Contents	Voltage - Input [Max]	Voltage - Input [Min]	Utilized IC / Part
Texas Instruments UCC28711D	Current Limiting Over Voltage	35 V	9 V	100 kHz	680 Hz	21 V	Isolated	7	8-SOIC	3.9 mm	0.154 in	7-SOIC	-40 °C	125 ¯C	Flyback	Surface Mount
Texas Instruments UCC28711EVM-160																	Flyback	5 V	AC/DC Primary Side	100 kHz	Fully Populated	5 W	1 A	Isolated	1	Board(s)	240 VAC	100 VAC	UCC28711
Texas Instruments UCC28711DR	Current Limiting Over Voltage	35 V	9 V	100 kHz	680 Hz	21 V	Isolated	7	8-SOIC	3.9 mm	0.154 in	7-SOIC	-40 °C	125 ¯C	Flyback	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 58.80

General part information

UCC28711 - AC/DC, Primary Side 1, Isolated Outputs Evaluation Board
