1805754

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 3 POS 5.08MM PITCH PLUG 24-12 AWG SCREW

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 3 POS 5.08MM PITCH PLUG 24-12 AWG SCREW

Technical Specifications

Parameters and characteristics for this part

Pluggable Terminal Blocks 3 Pos 5mm pitch Plug 24-12 AWG Screw

Part	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Wire Strip Length	Mounting Type	Voltage - IEC	Screw Size	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Contact Mating Finish	Pitch [x]	Pitch [x]	Color	Termination Style	Number of Levels	Positions Per Level	Current - IEC	Type	Features	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Insulation Height	Insulation Height	Plug Wire Entry	Housing Material	Voltage - UL	Material Flammability Rating	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Number of Positions
Phoenix Contact 1754047	0.2 mm˛	2.5 mm˛	7 mm	Free Hanging (In-Line)	250 V	M3	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Tin	5 mm	0.197 in	Black	Screw	1	3	12 A	Plug
Phoenix Contact 1805754	0.2 mm˛	2.5 mm˛	7 mm	Free Hanging (In-Line)	250 V	M3	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Gold	5.08 mm	0.2 in	Black	Screw - Rising Cage Clamp	1	3	12 A	Plug Female Sockets	Retention Latches (Wire Side)	30 AWG	12 AWG	1.024 "	26.01 mm	90 °
Phoenix Contact 1792029			7 mm	Free Hanging (In-Line)	630 V	M3	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Tin	5 mm	0.197 in	Green	Screw - Rising Cage Clamp	1	3	12 A	Plug Female Sockets	Retention Latches (Wire Side)	30 AWG	12 AWG	1.024 "	26.01 mm	90 °	Polyamide (PA) Nylon	300 V	UL94 V-0	0.2 mm²	2.5 mm²
Phoenix Contact 1786640				Free Hanging (In-Line)	250 V						Gold	5.08 mm	0.2 in	Green	Screw - Rising Cage Clamp	1	2	12 A	Plug Female Sockets	Retention Latches (Wire Side)	30 AWG	12 AWG			90 °		300 V		0.2 mm²	2.5 mm²	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 3 Pos 5mm pitch Plug 24-12 AWG Screw
